KCO-2000-RPL Rackmount Fanned Industrial Computer

Description

KCO-2000-RPL Rackmount Fanned Industrial Computer from Premio Inc.

2U Slim Form Factor (SFF) Chassis with Tool-less Mounting Options
Industrial Grade Micro-ATX Motherboard with Intel® Q670E PCH
Support 12th/13th/14th Gen Intel® Core™ Processors (LGA 1700, 65W Max TDP)
4x 288-pin DDR4 DIMM. Max. up to 128GB
1x 1GbE, 1x 2.5GbE Ports Support Wake-on-LAN, PXE
4x DP++ Independent Displays
1x PCIe x16 (Gen 5), 2x PCIe x4 (Gen 4, Gen 3), 1x PCIe x16 (Gen 4, 4-lane)
2x M.2 M Key, 1x M.2 E Key
6x RS-232 COM Ports (4x internal)
6x USB 3.1 Gen 2, 1x USB 3.2 Gen 2×2 Type C
Support uEFI Secure Boot, TPM 2.0
Tool-less Washable Dust Filter
Internal 250W Flex Power Supply
UL 62368 Ed. 3, FCC, CE

Additional information

Build/Mounting Options	RM – Rackmount
CPU Type	Intel CPU
Product Type	Rackmount PC

Key	Value
Processor	Support 12/13/14th Gen Intel® ADL & RPL S Processor (LGA 1200, 65W TDP) - Intel® Core™ i9-14900T/i9-13900TE/i9-12900TE, up to 24 Cores, 36MB Cache, up to 5.5 GHz - Intel® Core™ i7-14700T, up to 20 Cores, 33MB Cache, up to 5.2 GHz - Intel® Core™ i7-13700TE/i7-12700TE, up to 16 Cores, 30MB cache, up to 4.8 GHz - Intel® Core™ i5-14500T/i5-13500TE/i5-12500TE, up to 14 Core, 24MB Cache, up to 4.8 GHz - Intel® Core™ i3-14100T/i3-13100TE/i3-12100TE, up to 4 Cores, 12MB Cache, up to 4.4 GHz - Intel® Core™ 300T, up to 2 Cores, 6MB Cache, up to 3.4 GHz - Intel® Pentium® G7400TE, 2 Cores, 6MB Cache, 3.0 GHz - Intel® Celeron® G6900TE, 2 Cores, 4MB Cache, 2.4 GHz
LAN Chipset	GbE1: Intel® I219LM; 1GbE (Support Wake-on-LAN and PXE) GbE2: Intel® I225-V; 2.5GbE (Support Wake-on-LAN and PXE)
System Memory	4x DDR4 2133/2400/2666MHz DIMM. 128 GB Max
TPM	TPM 2.0
USB	6x USB 3.1 Gen 2 (10 Gbps) 1x USB 3.2 Gen 2x2 (20 Gbps) Type C 4x USB 2.0
Operating System	Windows 10, Linux Kernel 5.X
Storage	1x M.2 M Key: 2242/2260/2280 (NVMe, PCIe x4 Gen 4) 1x M.2 M Key: 2242/2260/2280 (NVMe/SATA, PCIe x4 Gen 4)
Expansion	1x M.2 E Key: 2230 (PCIe x1 Gen 3/USB 2.0), 1x PCIe x16 Slot (Gen 5) 1x PCIe x16 Slot (Gen 4, 4-Lane) 1x PCIe x4 Slot (Gen 4, Open End) 1x PCIe x4 Slot (Gen 3, Open End)
Audio	1x Mic-in, 1x Line-in, 1x Line-out
COM	2x RS-232
LAN	2x RJ45
Power Management	ACPI 5.0 compliant
Power Mode	100-240V AC @ 50/60Hz
Power Connector	IEC 60320 C14
Operating Temperature	0 °C to 40 °C
Storage Temperature	-40 °C to 85 °C
Dimensions	324(W) x 276(D) x 89(H) mm
Weights	5 KG (barebone w/ chassis, mb, and PSU only)
Form Factor	2U

Available Models
KCO-2000-RPL Fanned Industrial Computer with 2U Short-Depth, 12/13/14th Gen Intel® Core® Processor and Q670E PCH, PCIe Gen 5, USB Type-C

Optional Accessories
1-TPCD00005 Power Cord, 3-pin US Type, 180cm
1-TPCD00002 Power Cord, European Type, 180cm
1-TPCD00001 Power Cord, 3-pin UK Type, 180cm
