23” Apex23 Waterproof Nemacom Display
21.5" Nemacom Waterproof Monitor

23” Apex23 Waterproof Nemacom Display



  • Waterproof Display, IP66 Sealed (all 6-sides)
  • Fully Protected against Water and Dust ingress
  • 1920 x 1080 Full HD Resolution
  • Composite Video Input (option)
  • Multi-Touch PCAP Touchscreen available
  • 5-year Warranty



Download data sheet
Get a quote

Description

The APEX Range of Industrial Displays have been designed and built to withstand harsh, demanding environments.  Our range of Waterproof Displays are IP66 rated for peace of mind when water, chemicals or dust are present in your working environment, a full washdown of this product is also no problem.
Whether you choose to use them inside or outside we can guarantee their reliability which is why we can give our industry-leading 5-Year Warranty.

  • Enhanced Reliability and Performance
  • 5-Year Warranty
  • 6-Sides Fully IP66 Sealed
  • Ultra Wide Viewing Angle
  • 1920 x 1080 Full HD Resolution
  • VGA / HDMI / Composite Video Inputs
  • 10-Point Multi-Touch PCAP Touchscreen option
  • 100-240V AC Operation with external PSU (IP67 Sealed PSU option)
  • 12V, 24V, 48V DC Input options
  • Improved Shock/Vibration Resistance
  • Mild Steel or Stainless Steel Housing (Grade 304/316)
  • VESA Standard Interface Mounting
  • Highly competitive pricing and project support
  • UK Built & Supported, over 30 years Trading

Additional information

Display Size

23"
Additional Features

Widescreen, Grade 316 Stainless Steel Build (Medical / Food), Hi-Brite Technology Option, M12 Connectors, Colour Options Available
Build/Mounting Options

MC – Metal Cased, VESA Mount
Input Connections

VGA Input, HDMI Input, Composite Video Input
Product Type

Industrial Displays
Output Connections

USB Output (Touchscreen), RS232 Output (Touchscreen)
IP Rating

IP65/66 (Front Panel), IP65/66 (Fully Sealed)
Touchscreen Options

No Touch, PCAP Multitouch, Capacitive Touch, Resistive Touch
KeyValue
LCD23" TFT LCD, LED Backlights.
Resolution1920 x 1080 Full HD
Waterproof RatingAll 6-Sides Fully Sealed to IP66
Housing OptionsMild Steel painted (any colour option), Grade 304 or 316 Stainless Steel
Viewing Andle178° (H) / 178° (V)
Display Area509.2mm (H) x 286.4mm (V)
Brightness300 cd/m²
Contrast Ratio1000:1
Response Time14ms
Input OptionsVGA, HDMI, Composite Video
Power Supply100-240V AC External PSU (not IP sealed). Optional 12V, 24V, 48v DC Input option
Operating Temperature0°C to +50°C
Touchscreen Options10-Point Multi-Touch Projected Capacitive, USB or Serial Interface
AccessoriesNon-IP rated PSU (IP66 rated PSU option) UK Mains lead, Signal Cable (Touch Driver and Interface Cable for Touchscreen)
MountingRear VESA Mounting Interface
Weights & Dimension DrawingsContact us
ApprovalsUKCA

MC | Metal Cased: A rugged, fully housed industrial display.  This build option has industry standard, rear mounted VESA interface, a versatile mounting system which allows the display to be positioned on a wide range of wall brackets or desk stands.
