SID-X2N DisplayPort, HDMI, VGA & DVI Auto Switcher over HDBaseT

The SID−X2N is an HDBaseT twisted pair transmitter and step−in commander for computer graphics video, HDMI, DVI, DisplayPort and unbalanced stereo audio signals.

•  Max. Data Rate — 6.75Gbps (up to 1080p @60Hz 36bpp) in normal mode; up to 4.95Gbps (up to 1080p @60Hz 24bpp) in ultra mode.
•  HDTV Compatible.
•  HDCP Compliant — Works with sources that support HDCP repeater mode.
•  HDMI Support — Deep Colour, x.v.Color™ and 3D.
•  EDID Pass–through — Pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
•  Data Equalization and Reclocking.
•  Input Signal Detection — Based on video clock presence.
•  Automatic Input Selection — Based on manual selection or last connected input.
•  Automatic Analog Audio Detection and Embedding.
•  Local Balanced Audio De–Embedding.
•  Support for Digital Audio Formats.
•  Lockable EDID.
•  System Range — Up to 130m (430ft) at normal mode (2K), up to 100m at normal mode (4K); up to 180m (590ft) ultra mode (1080p @60Hz @24bpp) when using BC–HDKat6a cables.
•  Local Step–In Switching — Button & contact closure.
•  Power Supply — Requires independent power supply.
