12.1″ Nemacom Touchscreen Display.



  • Rugged Touchscreen Display; Front Sealed to IP66.
  • 1024 x 768 Resolution or Composite Video input.
  • Choice of Black, Stainless Steel or Bespoke Finish.
  • Panel Mount, Rackmount, Metal Case Options.
  • Available without Touchscreen.

5 year warranty Nemacom

Download data sheet

Get a quote

Description

The Technix T12 Industrial Display is a high specification, rugged 12.1” monitor designed and built in the UK.

The Technix range excels in build & picture quality using only high quality components.  The customer has a choice of mounting options and various finishes to the product, our robust, versatile Industrial Display is the ideal solution for a wide range of applications.

LCD 12.1" TFT LCD, 0.240mm x 0.240mm pixel pitch, LED Backlights.
Resolution 1024 x 768 XGA
Driver Element a-si TFT active matrix
Viewing Angle 160° (H) / 140° (V)
Display Area 245.76mm (H) x 184.32mm (V)
Colours 16.2 million
Brightness 600 cd/m²
Contrast 700:1
Response Time 16ms
Inputs T12: VGA, HDMI, Display Port | T12V: VGA, DVI-D, Composite Video & S-Video
Power Supply Standard: 100-240V AC (External PSU), Option: 12V, 24V, 48V DC
Power Usage T12: 10watts / T12-V: 12watts (typical)
Operation Temperature -20°C to +70°C
Approvals UKCA
Accessories Power Supply, UK Mains Lead, Signal Cable (Touch Driver USB Drive and Touchscreen Interface Cable for Touchscreen)
Touchscreen Option 3M Capacitive, USB or Serial Interface
Finish / Options Black, optional Stainless Steel or specified RAL colour.
Weights & Dimension Drawings Contact Us

PM | Panel Mount: A rugged, industrial display with an integrated front bezel.  This type of display is front-mounted into the customers housing, panel, workstation or other enclosure.  The customer is required to ‘cut-out’ an aperture in the housing to accept the rear of our display to fit through, studs on the rear of the bezel are then required to fit through drilled holes, the front bezel then sits flush with the surface of the housing, panel or workstation.

RM | Rackmount: A rugged, industrial display with an integrated 19" front bezel.  This type of display is mounted from the front into an industry standard 19" Server rack or a housing that utilises the ‘Rack-mounting’ system measured in "U" height.

MC | Metal Cased: A rugged, fully housed industrial display.  This build option is provided with studs/threads on the rear, arranged in a VESA mounting interface standard, which allows the display to be used with a whole range of VESA standard mounting Arms, Brackets and Stands.  (Ask us for more details)

EC | Enclosed Chassis: Sometimes referred to as 'Open-framed' or simply 'Chassis'.  An Enclosed Chassis LCD is a rugged, industrial display specifically designed for rear-mounting into the customers housing, panel, workstation or other enclosure.  The customer is required to 'cut-out' an aperture equal to the display area of the LCD, the unit has mounting brackets down either side to enable it to be fixed into position.
